Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Pocket size for C&B SD: 630 X 400 X 80mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 4 nos - 3” wheel power strip in rear side

Rear L.H Al. profile 45X45X525mm with swiveling

bracket and special laser cut CNC folded swinging and

clamping arrangement for display unit

https://vibrationmountsindia.com/

Granite base of size L 1100 X B 600 X T 30 mm

60 mm Tubular Structure

65 X 65 mm AV pads at 8 places

Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

"SCREW SUPPORT MOUNTS , Series DLKR

Dynemech Machine Base Mounts Series DLKR are simple but effective rectangular vibration dampers for machines with respective holes in the base. With their sturdy construction, Series DLKR supports both low frequency attenuation and stable precise machine levelling .

The DLKR Series of vibration damping and leveling mounts provide fast and easy installation of machines along with large rectangular area support. Series DLKR machine mounts provide enhanced component finish/part tolerance and extend tool and machinery life of all industrial and workshop equipment and machinery.

DLKR series Anti-vibration mounts have steel body and are used for machines having mounting holes in the base. This leveling mount has a cover plate and dimpled bottom plate holding the insulation plate.

Leveling is done by tightening the bolt which lifts the cover plate with the machine foot.

https://vibrationmountsindia.com/

Dynemech DLMS Series Antivibration Mounts, developed in steel and stainless steel respectively are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer low frequency attenuation, stable machine levelling and vibration reduction. The flexible levelling screw accommodates uneven/sloped surface up to 5 degree. DLMS Series find application where corrosion resistant materials for hygienic, climatic and environmental reasons are required like in pharmaceutical, food and beverages processing and packaging units, medical equipment manufacturing and chemical processing industries.

https://vibrationmountsindia.com/

Dynemech Spring Isolator

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine.

Model:MCI-E2 Load(Kg):96 HO:80 Free Height HI (mm):105 Bolt Size: M16x2.0x150 Top Plate AXB(mm):221X196 Bottom Plate CXD(mm):271X176 CC(mm):241 Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech Spring Isolator

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system.

https://vibrationmountsindia.com/

ynemech offers ANTI VIBRATION SHEETS made from high grade synthetic composite material. These sheets have different load capacities and are available in different natural frequencies to suit various industrial applications. These are resistant to water, oils, lubricating oils, fuels etc. used in the shop floor. Each sheet has defined stress value and can be placed directly under the machine as per the weight of the machine and no. of mounting positions. These plates will not deform plastically, if the weight of machine does not exceed maximum load value of the insulation plates. The available thicknesses are 2mm, 8mm, 15mm, 20mm, 25mm and 65mm.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RDD-E2-RT-SP2

Load(Kg):128 Free

Height HI (mm):161.5

Bolt Size: M16x1.75x100

Top Plate AXB(mm):235X235

Bottom Plate CXD(mm):235X235 CC(mm):205

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RCD-E2-RT

Load(Kg):96 Free

Height HI (mm):108

Bolt Size: M16x1.75x100

Top Plate AXB(mm):235X235

Bottom Plate CXD(mm):235X235 CC(mm):205

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RBD-E2-RT-SP2

Load(Kg):62 Free

Height HI (mm):161.5

Bolt Size: M16x1.75x100

Top Plate AXB(mm):235X235

Bottom Plate CXD(mm):235X235 CC(mm):205

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RBD-E2-RT

Load(Kg):62 Free

Height HI (mm):108

Bolt Size: M12x1.75x100

Top Plate AXB(mm):235X235

Bottom Plate CXD(mm):235X235 CC(mm):205

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech Spring Isolator

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RDD-E2 Load(Kg):128

Height Under Load HO(mm):103 Free Height HI (mm):112

Bolt Size: M16x2.0x150 Top Plate AXB(mm):232X207

Bottom Plate CXD(mm):271X176 CC(mm):241

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system.

Model:RDD-E2-RT

Load(Kg):128 Free

Height HI (mm):108

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RFD-H2-RT

Load(Kg):150-1200

Free Height HI (mm):108

Bolt Size: M20

Top Plate AXB(mm):300X300

Bottom Plate CXD(mm):300X300 CC(mm):260

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system.

https://vibrationmountsindia.com/

Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system.

Model:RCD-J2-RT-SP2

Load(Kg):82-900

Free Height H (mm):161.5

Bolt Size: M16 Top Plate AXB(mm):235x235

Bottom Plate CXD(mm):235x235 CC(mm):205

Natural Frequency Range(Hz):3.5-11

https://vibrationmountsindia.com/

Dynemech DMAS-SH4 system consists of three master pneumatic isolators for 3-point precision levelling. Each pneumatic damping isolator consists of a self-levelling plunger mechanism. Which is the load sensing, and heigh-controlling element. The system is supplied with pressure regulator, distributor, Clean dry air is required to be supplied to the system. The DMAS is lightweight aluminium body. The inner chamber is split into two parts i.e. load volume and damping volume. damping up to 20% can be adjusted using external valve manually. A thin reinforced elastomeric diaphragm supports the load. A safety valve protects diaphragm from over inflation. The final precise levelling of the system can be done using levelling nut provided on the plunger mechanism. Available levelling accuracies are ± 0.015 mm and ± 0.15 mm depending upon the application requirements. Natural frequency of the DMAS-SH1 system is 2.5-3 Hz.

https://vibrationmountsindia.com/

Dynemech Jackup mounts DJM-2 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.

Dia D(mm):- 90mm To 160mm

Height H(mm):-49mm To 49mm

G(mm): M20x2.5 Thread Length:38mm To M20x2.5mm

Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm)

Load Capacity:850Kg/pc To 2500Kg/pc Levelling Adjustment(mm):18 mm To 18 mm

Natural Frequency Range Hz: 18(Hz) To 18(Hz)

Coeff. of Friction: 0.9 To 0.9

Weight ( Kg.):1.5 Kgs To 5 Kgs

Working Temp Range: -16 to 90

https://vibrationmountsindia.com/

Dynemech Jackup mounts DJM-0 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.

Dia D(mm):- 90mm To 160mm

Height H(mm):-49mm To 49mm

G(mm): M20x2.5 Thread Length:38mm To M20x2.5mm

Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm)

Load Capacity:850Kg/pc To 2500Kg/pc

Levelling Adjustment(mm):18 mm To 18 mm

Natural Frequency Range Hz: 18(Hz) To 18(Hz)

Coeff. of Friction: 0.9 To 0.9

Weight ( Kg.):1.5 Kgs To 5 Kgs

Working Temp Range: -16 to 90

https://vibrationmountsindia.com/

Dynemech Level Grip Mounts Series DRM2-232-S2 Mounts levelling is done using a large lever screw. This screw transmits static and dynamic load of the machine on a larger area and thus provides greater stability to the machine. The levelling leaver requires lesser torque for lifting the machine while levelling.

Length:150(mm) To 232(mm)

Width:150(mm) To 232(mm)

Height:77(mm) To 77(mm)

Bolt Size:M16x2.0x100mm To M20x2.5x100mm

Levelling Adjustment: 20(mm) To 20 (mm)

Load Capacity: 1000 Kg/pc To 3300 Kg/pc

Natural Frequency (Hz):-8Hz To 8Hz

Coeff. of Friction: 0.8 To 0.8

https://vibrationmountsindia.com/

Dynemech Mac Level Series DML is suitable for high speed rotating machines having small or no axial forces.

Dia:50(mm) To 200 (mm) Height:40(mm) To 63(mm) Load Capacity: 175 to 4000 (Kg/pc)

d: 32(mm) To 120(mm)

Bolt Size: M10X1.5X100mm Long To M20X2.5X150mm Long

Levelling Adjustment: 10(mm) To 20(mm) Natural Frequency (Hz):7Hz To 8Hz

Working Temp Range °C: -16 to 90

Weight ( Kg.): 500Gm To 6Kgs

Material: Rubber+Cast Iron

https://vibrationmountsindia.com/

Dynemech Mac Level Series DML is suitable for high speed rotating machines having small or no axial forces.

Dia:160(mm) Height:58(mm)

Load Capacity: 2000 (Kg/pc)

d: 32(mm) To 120(mm)

Bolt Size: M10X1.5X100mm

Long To M20X2.5X150mm Long

Levelling Adjustment: 10(mm) To 20(mm)

Natural Frequency (Hz):7Hz To 8Hz

Working Temp Range °C: -16 to 90

https://vibrationmountsindia.com/

Dynemech Level Grip Mounts Series DRM1-150-S2 Mounts levelling is done using a large lever screw. This screw transmits static and dynamic load of the machine on a larger area and thus provides greater stability to the machine. The levelling leaver requires lesser torque for lifting the machine while levelling.

Length:150(mm) To 232(mm) Width:150(mm) To 232(mm) Height:77(mm) To 77(mm) Bolt Size:M16x2.0x100mm To M20x2.5x100mm

Levelling Adjustment: 20(mm) To 20 (mm)

Load Capacity: 1000 Kg/pc To 3300 Kg/pc

Natural Frequency (Hz):-8Hz To 8Hz

Coeff. of Friction: 0.8 To 0.8

Working Temp Range :16 to 90

Weight ( Kg.): 5 Kgs To 10 Kgs

https://vibrationmountsindia.com/

Dynemech Machine base mounts series SL5-P1 is Machine Base mounts used for light to medium weight machines suited to levelling screw support or having tapped hole in the base. These are suitable for placing in the pocket of the machine base.

Length – 80(mm) To 200(mm)

Width – 64(mm) To 200(mm)

Height- 30(mm) To 39(mm)

Load Capacity (Kg/pc.) 350 Kgs/pc To 1600 Kgs/pc

Natural Frequency (Hz):18 Hz To 7 Hz

Coeff. of Friction: 0.9 To 0.8

Working Temp Range °C: -16 to 90

Weight ( Kg.):0.5 Kg To 2.5 Kgs

https://vibrationmountsindia.com/

Dynemech Machine base mounts series SL1-u is Machine Base mounts used for light to medium weight machines suited to levelling screw support or having tapped hole in the base. These are suitable for placing in the pocket of the machine base.

Length – 80(mm) To 200(mm)

Width – 64(mm) To 200(mm)

Height- 30(mm) To 39(mm)

Load Capacity (Kg/pc.) 350 Kgs/pc To 1600 Kgs/pc

Natural Frequency (Hz):18 Hz To 7 Hz

Coeff. of Friction: 0.9 To 0.8

Working Temp Range °C: -16 to 90

Weight ( Kg.):0.5 Kg To 2.5 Kgs

https://vibrationmountsindia.com/

Granite base of size L 1100 X B 600 X T 50 mm

60 mm Tubular Structure with cross member

Wrap Around Construction with left angular profile

Swiveling bracket for monitor 65 X 65 mm AV pads at 8 places

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel Front keyboard panel for keyboard and mouse

https://vibrationmountsindia.com/

Passive Air Cushion AVT with electronic alarm

Aurdino- Uno controller based with limit switches

 for upper and lower position

with alarm buzzer and LED indicator

for high/low (HAL, Bangalore)

Passive Air Cushion AVT with electronic alarm

Aurdino- Uno controller based with limit switches

 for upper and lower position

with alarm buzzer and LED indicator

for high/low (HAL, Bangalore)

https://vibrationmountsindia.com/

Granite base of size: L 550 X B 750 X T 30 mm

60 mm Tubular Structure

Wrap Around Construction

Front keyboard panel to place keyboard and mouse

Left rear monitor mount with bracket to hold monitor

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel

https://vibrationmountsindia.com/

The Vibration Isolated Table (VIT) finds usage in critical areas where reading accuracy of instruments is affected by unwanted vibrations like Analytical Balances, Hardness Testers, Spectroscopes, Microscopes, Roughness Testers, Galvanometers, Profile Projectors, Atomic Force Microscopes, Roundness Testers, Electronic Microscopes and Atomic Absorption Spectrophotometers.

Granite base of size: L 1000 X B 600 X T 80 mm

60 mm Tubular Structure

Wrap Around Construction 4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel 4 No’s – 3” Wheel 4 No’s – 3” Wheel

https://vibrationmountsindia.com/

Granite base of size L 800 X B 900 X T 767 mm

60 mm Tubular Structure with wrap around construction.

Front joystick panel laser cut with top rim and Z-plates at bottom to lock joystick.

All three sides closed, bottom sheet to place controller, CPU and UPS; with exhaust fan. Front double door with handles and lock.Power strip in rear; Leveling Ball, Spanner 24/27

Powder Coat, structure and joystick panel RAL 9002

https://vibrationmountsindia.com/

Granite base of size L 650 X B 900 X T 767 mm

60 mm Tubular Structure with wrap around construction.

Front joystick panel laser cut with top rim and Z-plates at bottom to lock joystick.

All three sides closed, bottom sheet

to place controller, CPU and UPS; with exhaust fan.

Front double door with handles and lock.

Power strip in rear; Leveling Ball, Spanner 24/27

Powder Coat, structure and joystick panel RAL 9002

https://vibrationmountsindia.com/

Granite base of size L 750 X B 600 X T 30 mm

60 mm Tubular Structure with cross member

Wrap Around Construction with left angular profile

Swiveling bracket for monitor

65 X 65 mm AV pads at 8 places

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level

4 No’s – 3” Wheel Front keyboard panel for keyboard and mouse

https://vibrationmountsindia.com/

Granite base of size L 1100 X B 600 X T 60 mm

with keyboard panel open space for controller, drawer and space for printer

Granite base of size L 1100 X B 600 X T 60 mm

with keyboard panel open space for controller, drawer and space for printer

https://vibrationmountsindia.com/

Granite base of size L 600 X B 760 X T 767 mm

60 mm Tubular Structure with wrap around construction.

Front joystick panel laser cut with top rim and Z-plates at bottom to lock joystick.

All three sides closed, bottom sheet to place controller, CPU and UPS; with exhaust fan.

Front double door with handles and lock. Power strip in rear; Leveling Ball, Spanner 24/27

Powder Coat, structure and joystick panel RAL 9002

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 650 X B 900 X T 767 mm

60 mm Tubular Structure with wrap around construction.

Front joystick panel laser cut with top rim and Z-plates at bottom to lock joystick.

All three sides closed, bottom sheet

to place controller, CPU and UPS; with exhaust fan.

Front double door with handles and lock.Power strip in rear; Leveling Ball, Spanner 24/27 Power strip in rear; Leveling Ball, Spanner 24/27

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite size L 600 x B 900 x T 50 mm over steel structure

60 x 60 mm Square Tubular Structure with cross member

Wrap around construction

4 Nos. 4’’ wheels

4 Nos. DLP4 AV discs at floor level

9 Nos. 65 x 65 mm AV Pads between Granite and structure

Front double door with handles and lock

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 600 X B 900 X T 767 mm

60 mm Tubular Structure with wrap around construction.

Front joystick panel laser cut with top rim and Z-plates at bottom to lock joystick.

All three sides closed, bottom sheet

to place controller, CPU and UPS; with exhaust fan.

Front double door with handles and lock.Power strip in rear; Leveling Ball, Spanner 24/27

Powder Coat, structure and joystick panel RAL 9002

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 750 X B 600 X T 30 mm

60 mm Tubular Structure with cross member

Wrap Around Construction with left angular profile

Front keyboard panel for aesthetic purpose

Pneumatic supported membrane air springs with 3 sensors and auto leveling within ± 0.15 mm complete with manifold and regulator, FRL unit, shut-off wall and NRV. Completely enclosed in laser cut SS side sheet. Printer Stand (To be Ordered Separately)

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 450 X B 750 X T 30 mm

60 X 60 mm Tubular Structure to Suit Granite size 450 X 750 X 30 mm

Wrap Around Construction with front extended cover for aesthetics

4 No’s – 2” Caster wheels Power Strip in Rear & Drawing Pouch on L.H Side Front single door with handles and lock Leveling Ball, Spanner 24/27

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

60 mm Tubular Structure

Top Surface area L 400 X B 750 mm

Top sheet metal 8 mm thick welded to tubular structure covered with L – plates with 80 mm dia laser cut hole. 4 No’s Caster Wheels

Drawing Pouch LH Side, cable manager at rear side Front single door with handle and lock Leveling Ball

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 750 X B 600 X T 30 mm

60 mm Tubular Structure with cross member

Wrap Around Construction with left angular profile

Swiveling bracket for monitor

Front keyboard panel for keyboard and mouse

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 1200 X B 600 X T 50 mm

60 mm Tubular Structure

65 X 65 mm AV pads at 8 places

Front keyboard panel with laser cut joystick pocket for Joystick

Additional printer stand to accommodate CPU console,

monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm Wrap around construction

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/

Granite base of size L 750 X B 600 X T 30 mm

60 mm Tubular Structure

65 X 65 mm AV pads at 8 places

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel

Front keyboard panel with laser cut joystick pocket for Joystick

Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

https://vibrationmountsindia.com/
